100U1000A
EMC Power Amplifiers by AR RF/Microwave Instrumentation
Download Datasheet
Request Quote
Note: Your Quotation Request will be directed to AR RF/Microwave Instrumentation.
The 100U1000A from AR RF/Microwave Instrumentation is a EMC Power Amplifiers with Frequency 0.01 to 1000 MHz, Gain 52 to 56 dB, Gain Control Range` 20 to 25 dB, Noise Figure 8 dB, Power (dBm) 45.44 to 52.04 dBm. More details for 100U1000A can be seen below.
Product Specifications
Product Details
- Part Number100U1000A
- ManufacturerAR RF/Microwave Instrumentation
- DescriptionSolid State Power Amplifier from 0.01 to 1000 MHz
General Parameters
- Frequency0.01 to 1000 MHz
- Gain52 to 56 dB
- Gain Control Range`20 to 25 dB
- Noise Figure8 dB
- Gain flatness±1.5 to ±2 dB
- Power (dBm)45.44 to 52.04 dBm
- Power (W)35 to 160 W
- P1dB (dBm)45.44 to 52.04 dBm
- IP3 (dBm)60 dBm
- Saturated Power50 to 51.76 dBm
- TypeSolid State Power Amplifier
- AC Voltage100 to 240 V
- Power Consumption450 W
- Impedance50 Ohms
- VSWR1.50:1, 2.00:1
- Input VSWR1.50:1, 2.00:1
- EMC StandardsISO 9001, EN 61326-1
- InterfaceRS-232, USB, Ethernet, GPIB, Fiber-Optic Serial, IEEE-488
- ApplicationsGeneral RF/EMC Testing, 5G EMC Testing, Wireless Communication
- Package TypeBenchtop / Rackmount
- ConnectorsN Type, N Type - Female
- Input ConnectorN Type - Female
- Output connectorN Type - Female
- Cooling OptionsBuilt-in Fan Cooling, Air Cooled
- Weight26.5 kg
- Storage Temperature-20 to 50 Degree C
- RoHSYes
- Note :P3dB Power : 80 to 160 W
