EMV 2025 Update
Date: 25 March, 2025

Top Products Showcasing at EMV 2025

EMI Microwave Antenna from 14.9 to 44 GHz

EMC Antenna from Rohde & Schwarz Product Details

The R&S HF1444G14 from Rohde & Schwarz is an EMI Microwave Antenna that operates from 14.9 to 44 GHz. It delivers a gain of 14 dBi and has a 3 dB half-power beamwidth of more than 28°. This antenna meets the requirements of CISPR 16-1-4 and CISPR 16-2-3 (updated) standards. It is designed to deliver precise electromagnetic interference (EMI) measurements of devices in the FR2 frequency range. View details

Download Datasheet

EMI Signal Generator from DC to 200 kHz

EMI Signal Generator from AE Techron Product Details

The DSR 100-25 from AE Techron is an EMI Signal Generator that generates signals in a bandwidth (-3dB) of DC to 200 kHz. It produces sine wave sweep, ripple (cranking), DC source, triangle wave, square wave, and sawtooth waveforms with a rise time of less than 3 µs. It can function as a controller or node in a larger test system via these built-in LAN and GPIO controls. View details

Download Datasheet

Double-Ridged Horn Antenna from 800 MHz to 6 GHz

EMC Antenna from RFspin Product Details

The DRH0806 from RF SPIN is a Double-Ridged Horn Antenna that operates from 800 MHz to 6 GHz. It delivers a power of 1000 W(CW), a peak power of up to 1300 W, and a gain of 10-24 dBi. This linearly polarized antenna has an antenna factor of 17-24 dB/m and a VSWR of less than 1.8:1. It is ideal for electromagnetic interference testing and other general-purpose applications. View details

Download Datasheet

EMI Receiver with Spectrum Analyzer from 9 kHz to 26.5 GHz

EMI Receiver from GAUSS INSTRUMENTS Product Details

The TDEMI® 26G from GAUSS INSTRUMENTS is an EMI Receiver with a frequency range from 9 kHz to 26.5 GHz. It uses leading-edge high-resolution and high-speed analog-to-digital converters and modern FPGAs, and in-house designed high-performance microwave circuits to achieve high measurement accuracy and measurement speed. View details

Download Datasheet

Sponsored by IMS 2025

Registration for IMS2025 is now open! Take advantage of the lowest rates today.

The IEEE MTT-S International Microwave Symposium (IMS2025) is headed to San Francisco, CA, 15-20 June 2025. IMS2025 is the premier event where the RF and microwave industry gathers for networking, education, and the largest industry exhibition. Click here to learn more.

EMC Test Software for Automation of Conducted and Radiated Immunity Tests

EMC Test Software from NEXIO Product Details

The BAT-EMC Immunity from NEXIO is an EMC Test Software that enables the automation of conducted and radiated immunity tests. It supports various types of calibration and testing, such as conducted current, conducted voltage, radiated electric, radiated magnetic, etc. t supports different regulation methods like open loop or substitution, closed loop, power limitation, current limitation, and generator control. View details

Download Datasheet

12 kW Switch-Mode Amplifier from DC to 250 kHz

EMC Power Amplifiers from AE Techron Product Details

The 8712 from AE Techron is a Switch-Mode Amplifier that operates from DC to 250 kHz. It delivers an output power of up to 12 kW (120 kVA) and a continuous output current of up to 180 A RMS with an efficiency of 85%. This amplifier is fast enough for DC automotive dropout testing and capable of AC voltages required for ISO 61000 and aviation testing. View details

Download Datasheet

Solid State Power Amplifier from 18 to 40 GHz

EMC Power Amplifiers from Exodus Advanced Communications Product Details

The AMP20005 from Exodus Advanced Communications is a Solid-State Power Amplifier (SSPA) that operates from 18 to 40 GHz. It delivers a saturated CW output power of more than 30 W with a power gain of more than 44 dB and has a gain adjustment range of 20 dB. This amplifier has a 2-tone intermodulation of -30 dBc and an input return loss of less than -10 dB. View details

Download Datasheet
