R&S®FPS40
Spectrum Analyzer by Rohde & Schwarz (44 more products)The R&S®FPS40 from Rohde & Schwarz is a Spectrum Analyzer with AC Voltage 100 to 240 V, Attenuation 0 to 10 dB, Frequency 10 Hz to 40 GHz / 10 MHz to 40 GHz, Phase Noise -150 to -84 dBc/Hz. More details for R&S®FPS40 can be seen below.
Product Specifications
Product Details
- Part Number :R&S®FPS40
- Manufacturer :Rohde & Schwarz
- Description :SIGNAL AND SPECTRUM ANALYZER
General Parameters
- Analysis Bandwidth :160 MHz
- Connectors :2.92 mm, 2.92 mm - Female BNC, BNC - Female
- Current :3.5 A
- DANL :-160 to -90 dBm
- Dimensions :18.15 x 4.21 x 21.69 Inches
- Impedance :50 Ohms
- IP3 :12 to 18 dBm
- Operating Temperature :5 to 40 Degree C
- Power Consumption :165 to 10 W
- Real Time :No
- Storage Temperature :-40 to 70 Degree C
- Type :Benchtop with Screen
- Weight :11.7 kg (25.80 lb)
- AC Voltage :100 to 240 V
- Attenuation :0 to 10 dB
- Frequency :10 Hz to 40 GHz / 10 MHz to 40 GHz
- Phase Noise :-150 to -84 dBc/Hz
Technical Documents
- Datasheet
