N5171B

EMI Signal Generator by Keysight Technologies (4 more products)
Download Datasheet Request Quote

Note: Your Quotation Request will be directed to Keysight Technologies.

The N5171B from Keysight Technologies is a EMI Signal Generator with Frequency 9 KHz to 1, 3, 6 Or 7.2 GHz, Harmonics -53 to -35 dBc, Phase Noise -133 to -103 dBc, Resolution 0.001 Hz. More details for N5171B can be seen below.

Product Specifications

Product Details

  • Part Number :
    N5171B
  • Manufacturer :
    Keysight Technologies
  • Description :
    9 KHz to 1, 3, 6 Or 7.2 GHz EMI Sgnal Generator

General Parameters

  • Dimensions :
    3.5 x 16.8 x 19.2 Inch (H x W x L)
  • Fall Time :
    7 to 10 nS
  • Interface :
    GPIB, LAN, USB 2.0, SCPI
  • Modulation :
    AM, FM, PM, Pulse, Internal I/Q 2, External I/Q 2, Phase
  • Package Type :
    Benchtop
  • Rise Time :
    7 to 10 nS
  • Type :
    Analog
  • Frequency :
    9 KHz to 1, 3, 6 Or 7.2 GHz
  • Harmonics :
    -53 to -35 dBc
  • Phase Noise :
    -133 to -103 dBc
  • Resolution :
    0.001 Hz

Technical Documents

View more details on the manufacturer's website
