HS-075-UBR-10T-SF
EMC Antenna by Fei Teng Wireless Technology
Request Quote
Note: Your Quotation Request will be directed to Fei Teng Wireless Technology.
The HS-075-UBR-10T-SF from Fei Teng Wireless Technology is a EMC Antenna with Frequency 10 to 15 GHz, Gain 10 dB, Input Power 300 W, Horizontal BW 42 Degree, Vertica BW 42 Degree. More details for HS-075-UBR-10T-SF can be seen below.
Product Specifications
Product Details
- Part NumberHS-075-UBR-10T-SF
- ManufacturerFei Teng Wireless Technology
- DescriptionWR75 Standard Gain Feed Horn Antenna, 10GHz to 15 GHz, 10dbi gain, UBR Flange, SMA-Female Connector
General Parameters
- Frequency10 to 15 GHz
- TypeFeed Horn
- DirectionalityDirectional
- Gain10 dB
- PolarizationVertical, Horizontal
- Input Power300 W
- VSWR1.25:1
- Horizontal BW42 Degree
- Vertica BW42 Degree
- MaterialAluminium
- ApplicationsEMI/EMC Testing, Antenna Gain Measurements
- Dimensions40 x 40 x 85.4 mm
- ConnectorsSMA, SMA - Female
- WaveguideWR-75
- Weight0.12 Kg
